Solar Mounts for Flat Roofs - Angle bar triangle kit
· Design Features
① Pre-assembled angle bar triangle kit is convenient to install.
② Angle can be fixed or adjusted 10-30° or 30-60°.
③ Suitable for portrait panel installation.
· Surface treatment:
10μm thk. Anodized aluminum, stainless steel 304 bolts and nuts.
· Design Strength:
Suited for different range of wind load and snow load.
· Certification:
Australia AS/NZS 1170.2-Wind load report; SGS report-Chemical&Physical test.
|
Suitable for |
concrete flat roof |
|
Module |
Framed, thin film |
|
Material&Surface treatment |
10um thk. Anodized Aluminum 6005-T5, stainless steel 304 bolts and nuts |
|
Color |
silver, black or customer requirement |
|
Module orientation |
Landscape and portrait |
|
Wind load |
Max 60m/s |
|
Snow load |
Max 1.5kn/m2 |
|
Standards |
Australia AS/NZS 1170.2, CE,SGS,DIN 1055,JIS |
|
Warranty |
20 years |
Category : Flat Roof Mount
 |
 |
 |
| AS-DR-01A |
AS-DR-01B |
AS-DR-03 |
 |
 |
 |
|
AS-DR-04 |
AS-DRS-01 |
AS-DRS-02 |
 |
 |
 |
|
AS-DEC |
AS-DMC |
AS-LC-01-D |
 |
 |
|
|
AS-AB-B |
Pre-assembled structure |
|
 |
|
Step 1
Open the pre-assembled triangle kit |
 |
 |
|
Step 2
Fix solar rail on the triangle kit
|
 |
 |
|
Step 3
install solar panel on the triangle kit
|
FLAT roof - Angle bar triangle kit
 |
|
 |
