solar panel structure mounting brackets
· Design Features
① Few components, flexible installation: cut or joint the steel pipe when ramming pile at site.
② e nut design: 3 slots design which is perfectly matched 18# aluminum rail slot.
· Surface treatment:
80μm thk. Hot dipped galvanizing steel, 10μm thk. Anodized aluminum, stainless steel 304 bolts and nuts.
· Foundation type:
Pile driven, ground screw, concrete pad.
· Design Strength:
The structure is designed according to the wind load or snow load request.
· Certification:
Australia AS/NZS 1170.2-Wind load report; SGS report-Chemical&Physical test.
|
Suitable for |
Open field |
|
Module |
Framed, thin film |
|
Material&Surface treatment |
10um thk. Anodized Aluminum 6005-T5, stainless steel 304 bolts and nuts |
|
Color |
silver, black or customer requirement |
|
Module orientation |
Landscape and portrait |
|
Wind load |
Max 60m/s |
|
Snow load |
Max 1.5kn/m2 |
|
Standards |
Australia AS/NZS 1170.2, CE,SGS,DIN 1055,JIS |
|
Warranty |
20 years |
 |
 |
 |
| AS-R-18 |
AS-RS-02 |
AS-TCP |
 |
 |
 |
|
AS-TEP |
AS-TAS |
AS-PC |
 |
 |
 |
|
AS-BPS-01 |
AS-BPS-02 |
AS-BPS-03 |
 |
 |
 |
|
AS-MC |
AS-EC |
AS-EC02 |
 |
 |
|
|
AS-TED |
AS-UB |
|
solar panel structure mounting brackets
 |
|
Step 1 Pile into soil ground |
 |
 |
|
Step 2 Rail installation |
 |
 |
|
Step 3 Solar module installation |
solar panel structure mounting brackets
Category : Steel Ground Mount
 |
|
 |
